Description
***OPTIC KIT DOES NOT INCLUDE WILCOX FTS MOUNT***
***STD KIT INCLUDES WILCOX FTS MOUNT***
The Pixels on Target VooDoo-S is a short/medium range multi-mission thermal sight. The VooDoo-S is the next generation of tactical thermal imaging. We’ve kept what you require, improved what you’ve asked for, and added that you’ve always desired. Feature rich, yet easy to use. All in one hand, all under 10-ounces. VooDoo-S is a multi-mission uncooled thermal imaging sight designed and optimized for small and medium caliber weapons as a true Clip-On. It also serves as a stand-alone sight, hand-held viewer, or helmet-mounted system. The VooDoo-S also features a Class 1 Eye-Safe IR laser which is extremely useful for marking targets for other users equipped only with image intensified night vision .
VooDoo-S provides the sharpest thermal images on the market, utilizing a shutterless 12-micron, 640 x 480 PIXELS core powered by an advanced focal plane array and thermal image processor. VooDoo-S is mission-ready and includes a flip-to-side / QD mount that allows seamless transition from day optics to thermal sight while maintaining zero. VooDoo-S features advanced ergonomic design for one-handed operation, tactile-positive feedback, and silent buttons that are easily manipulated while wearing gloves.
VooDoo-S provides accuracy to <0.5 MOA at 100 yards. To further demonstrate VooDoo-S’ accuracy, we put 5 rounds of 5.56 through a single 5.56 shell cases to simulated a thermal target @ 25 yards. VooDoo-S features a patent pending dual-lateral Matrix adjustment mechanism to achieve zero POA/POI shift.
VooDoo-S is built tough to withstand any small arms calibers. We tested without failure or bullet impact shift, 500 rounds of 7.62 x 51 NATO through the SCAR-17 Heavy.
VooDoo-S has advanced features to include integrated Artifical Intelligence and Machine Learning that no other optic of its size, weight and power offers on the world market.
VooDoo-S is the first micro thermal optic to offer such power and connectivity for our modern warfighters. The ability to load mission specific profiles, integrated communications via secured links and friend or foe designators reducing Blue-on-Blue Safety issues.
**THIS PRODUCT IS ITAR CONTROLLED AND CANNOT BEÂ PURCHASED BY NON U.S. PERSONS, SOLD, OR EXPORTED OUTSIDE OF THE USA***
SPECS
Caliber | 7.62x51 - SCAR 17 Heavy |
---|---|
Sensor | 640 x 480 Microbolometer |
Spectral Range | 7.5 - 13.5μm (LWIR) |
Pixel Pitch | 12 μm |
Pixel Format | <50 mK |
Digital Zoom | 0.5x / 1x / 2x / 4x |
NUC | Shutterless |
FOV | 19° Diagonal (15° (H) x 11.3° (V) |
MoA | 1 |
Optical Magnification | UNITY |
Scope Compatibility | Up to 8x |
Reticle | Cross-har, MIL-Dot, SVC, (CUSTOM) |
Polarity | Black Hot/ White Hot/ White Edge/ Black Edge/ Dynamic |
Identification | 250 Yards |
Recognition | 500 Yards |
Detection | 1000 Yards |
Laser Pointer | 850nm, 0.7mW, Class 1 Eye Safe |
Digital Compass | Yes |
Display Type | OLED Monochrome |
Display Resolution | 640 x 480 |
Light Guard | Open Eye Cup |
Diopter | Adjustable +/- 2D |
Refresh Rate | 60Hz |
Mount | Picatinny, MIL-STD-1913, NVG Interface, QD FTS, Return to Zero |
Video Out | VBS: 1.0 Vp-p, RS170 |
Signal System | NTSC / PAL |
Control | Keypad and/or Optional Remote Pad |
Start Up Time | <5 seconds |
Battery | 1x CR123A |
Battery Run Time | <3 Hours |
Weight | 10 oz |
Water Immersion | 1M depth, 2 Hours, MIL-STD-810G, 512.5, Procedure I |
Shock & Vibration | MIL-STD-810G, Dust & Sand, MIL-STD-810G, 510.5 Procedure I |
Operating Temp | -32°C to 55°C, MIL-STD-810G, 501.5, Procedure 1 & 502.5, Procedure 1 |
Storage Temp | -40°C to 65°C, MIL-STD-810G, 501.5, Procedure 1 & 502.5, Procedure 1 |
Humidity | >95% MIL-STD-810G, 507.5, Procedure 2MIL-STD-810G, 507.5, Procedure 2 |
Warranty | 1 Year |
Included Accessories | BNC Cable (Video Out), USB Cable (Data and Image Transfer), Eye Cup, BNC Coupler, 3v Lithium Battery, Quick Reference Guide, Voodoo-S Manual, Operation / Download Software |
